Snow Guards For Ash & Lacy Standing Seam Metal Roof Panels

See the Snow Guards Compatibility Chart for Ash & Lacy Standing Seam Metal Roofing.

Ash & Lacy standing seam metal roofing panels often require non-penetrating snow retention systems designed around specific panel configurations. Below are compatible SnoBlox-Snojax snow guard and snow retention products with key considerations for these roof profiles.

Standing Seam Profile

Ash & Lacy's Standing Seam system is a versatile roof and wall cladding solution that has served the UK construction industry for more than 20 years. It features standard panel widths of 300 mm (approximately 11.81 inches) and 400 mm (approximately 15.75 inches), with a 50 mm (approximately 1.97-inch) seam height, and can be manufactured in lengths up to 30 meters (approximately 98.4 feet), minimizing end laps for a sleek appearance. The system is available in various materials and thicknesses, including aluminum (0.9mm, 1.2mm), steel (0.7mm, 0.9mm), copper (0.6mm, 0.7mm), and zinc (0.7mm, 0.8mm). It can be installed on roof pitches as low as 1.5 degrees, making it suitable for diverse architectural designs. The Standing Seam system ensures durability across weather conditions while promoting efficient water drainage. It has been successfully used in notable projects like Sandwell College in Birmingham and includes the BBA Certified AshZip variant. The Standing Seam system combines quality, versatility, and performance, making it a popular choice for public and private sector projects among specifiers and contractors. See the Snow Guards Compatibility Chart for Ash & Lacy Standing Seam Metal Roofing.

Flat configurations of this roofing system may accept adhesive-mounted polycarbonate snow guards when the panel material, finish, and bonding surface are suitable for SureBond SB-190. Proper application of adhesives is crucial to avoid problems such as refreezing and detachment, which can arise when moisture collects between the snow guards and the roof panels. Due to this panel's striations, a thicker adhesive application may be necessary to achieve proper contact and fit. Customers have a range of options, including larger units like IceJax II, Snojax II, and SnoBlox Ace, as well as more compact alternatives such as Ecojax, SnoBlox Deuce, and IceJax I. SnowBreaker and SnowBreaker 3M are designed to help break sliding snow and ice into smaller, less hazardous pieces. The unique bulb-shaped rib design of this panel allows for the use of some of our clamp-on snow guards and rail systems, such as the SnoCleat RCT and the SnoBar or ColorBar systems when mounted with the RoofClamp RCT in either an RCB-3 or 2-Bar configuration. It's important to note that this panel is incompatible with standard SnoBar clamps or RoofClamp RC. Testing a clamp sample before finalizing an order is advisable to ensure proper fit. Given that aluminum and copper roof panels are softer than steel panels, it may be necessary to incorporate additional rows during the installation of clamp-on snow retention to compensate for the lower strength of the panels. Individual polycarbonate glue-down snow guards are not recommended for this panel's curved configurations. These guards require a flat surface for proper attachment, which is impossible on curved panels. We recommend clamp-on bar systems or SnoCleats for optimal snow retention on radiused panels.

Optimize Your Roof's Aesthetics with Color-Matched Snow Guards

Enhance your roof's appearance by selecting snow retention systems that complement its design. Explore options like custom powder-coated guards or products with color-coordinated metal inserts. Consider local powder coating services or try painting the guards for a quick, cost-effective solution.

Address Ice-Related Challenges

In areas prone to icing, incorporate specialized components like IceStopper snow rail accessories into your snow retention system. Properly selecting and placing these items is crucial, especially for roofs with higher seams, to combat ice-related issues effectively.

Schedule Installation Strategically

For adhesive-mounted systems, plan your installation during warmer months, preferably in late spring or early summer. Consider ambient temperatures when determining curing times for optimal adhesion. SureBond SB-190 requires 28 days at 50 degrees Fahrenheit or above to fully cure.

Verify System Compatibility

Before installing, test-fit our system components to ensure they're compatible with your roof type. This crucial step helps prevent costly mistakes and ensures smooth integration. To facilitate testing, consider purchasing individual system parts and accessories separately.

Safeguard Your Entire Roof Surface

Develop a comprehensive approach to protecting your entire roof. Consider implementing multiple rows of evenly distributed snow retention elements to prevent stress concentration in specific areas. Use our resources, such as spacing guidelines and quote request tools, to ensure optimal placement.

Customize Your Snow Retention Strategy Based on Local Conditions

Before selecting a system, confirm the project’s ground snow load and other roof conditions. Individual snow guards are generally best suited for lighter snow-load applications. Ground snow loads above 45 psf typically require a rail system designed from a project-specific layout.

Maintain Your Roof's Structural Integrity

When selecting attachment methods, prioritize options that preserve your roof's integrity, especially for standing seam metal roofing. Consider non-penetrating, surface-mounted solutions like clamp-on or adhesive-based systems to avoid unnecessary roof penetrations and help preserve the roof’s weather-resistant design.

Conclusion

SnoBlox-Snojax provides excellent customer support for snow guard installations, focusing on long-lasting solutions rather than quick fixes. Our main goal is to help customers understand our products thoroughly. We offer personalized assistance and various online resources to equip clients with the knowledge and tools they need for successful installations. Customers have direct access to our support team and can use practical guides to get the most out of our products. We are committed to quality and customer satisfaction. To aid decision-making, we've created helpful resources like a Snow Guard Buyer's Guide and a "What Works and What Doesn't" page. We encourage customers needing help with their orders to contact our support team by phone or email for guidance. Our customer support approach aims to empower clients with the necessary knowledge and tools for effective snow guard installations, ensuring a great experience and excellent results for everyone.
