Snow Guards For Standing Seam Metal Roof Panels by ACI Building Systems

See the Snow Guards Compatibility Chart for ACI Building Systems Standing Seam Metal Roofing Panels.

ACI Building Systems standing seam roof systems require snow guards and snow retention solutions compatible with the seam geometry and attachment method of each panel profile. Below are compatibility considerations and recommended SnoBlox-Snojax systems for ACI Building Systems standing seam panels.

SnapLok Panel

The SnapLok panel by ACI Building Systems is a sophisticated concealed fastener roof system tailored for residential and commercial applications. Characterized by a 1-3/4" high rib, this panel is available in 16" and 18" widths. Constructed from high-quality materials, the SnapLok panel comes in 24-gauge and 22-gauge steel. It comes in ACI's standard color options, coated with AZ50 (minimum) aluminum/zinc alloy for a painted finish or AZ55 aluminum/zinc alloy for an unpainted finish for added durability. The SnapLok panel is designed for easy installation and features a male and female rib design that ensures secure interlocking. Performance-wise, the panel has been tested for wind uplift resistance. It holds a UL 580 Class 90 rating, ensuring its robustness in adverse weather conditions. The concealed fasteners provide a sleek and modern appearance, making the SnapLok panel suitable for various architectural styles while ensuring excellent weather-tightness. See the Snow Guards Compatibility Chart for ACI Building Systems SnapLok Standing Seam Metal Roofing Panels.

This roofing system offers a variety of snow retention solutions. It is particularly compatible with adhesive-mounted polycarbonate snow guards. However, ensuring the correct adhesive application is essential to avoid problems such as refreezing and detachment due to moisture. Customers can choose from a broad range of snow guard options, including larger models like IceJax II, Snojax II, and SnoBlox Ace, as well as smaller models like the Deuce and IceJax I. For enhanced safety during snow and ice shedding, we recommend the SnowBreaker and SnowBreaker 3M. The panel's rib configuration appears to work well with various clamp-on snow guards, such as SnoCleat RC, SnoCleat RCT, SnoBar, and ColorBar rail systems, which can be mounted using either standard stainless steel SnoBar clamps or aluminum RoofClamp alternatives. Testing-fit a clamp sample before finalizing an order for one of these systems is advisable.

StratoShield Panel

ACI Building Systems offers the StratoShield, an advanced metal panel system that combines exceptional weather resistance with structural strength and visual appeal. The StratoShield comes in a standard 24-inch width with a 3" high rib. The exterior of the panel features a subtly corrugated profile with small striations. The StratoShield is well-suited for various building types, including commercial, industrial, and institutional structures. This panel is available in 24 and 22-gauge options. Its engineered design ensures excellent protection against air and moisture infiltration, making it a top choice for builders seeking a balance of energy efficiency, durability, and architectural flexibility. The StratoShield exemplifies ACI Building Systems' commitment to meeting the evolving needs of modern construction with high-performance, versatile building solutions. See the Snow Guards Compatibility Chart for ACI Building Systems StratoShield Standing Seam Metal Roofing Panels.

This roofing system provides various snow retention solutions thanks to its design. It is ideal for adhesive-mounted polycarbonate snow guards. Still, proper adhesive application is vital to avoid moisture-related issues like refreezing and detachment. Customers have a wide array of snow guard options, including larger models like IceJax II, Snojax II, and SnoBlox Ace, as well as smaller ones like the Deuce and IceJax I. For better safety during snow and ice shedding, we recommend using the SnowBreaker and SnowBreaker 3M. The rib configuration of the panel seems to be compatible with various clamp-on snow guards, such as SnoCleat RC, SnoCleat RCT, SnoBar, and ColorBar rail systems, which can be mounted using standard stainless steel SnoBar clamps or aluminum RoofClamp alternatives. Testing-fit a clamp sample before making a final purchase decision for one of these systems is recommended.

UltraLok Panel

The UltraLok panel, a product of ACI Building Systems, is a versatile standing seam metal roofing solution designed for various construction applications. This high-performance panel offers a range of dimensions to suit different project needs. With a maximum width of 18 inches and a minimum of 16 inches, the UltraLok panel provides flexibility in coverage. Its distinctive 2-inch rib height contributes to its aesthetic appeal and functional design. ACI Building Systems offers the UltraLok panel in two steel gauge options: 22 and 24. This variety in thickness allows builders to select the most appropriate panel for their specific load-bearing requirements and project specifications. The standing seam profile of the UltraLok panel not only enhances its visual appeal but also significantly improves its weather-resistant capabilities. This design feature and concealed fasteners ensure a sleek appearance while maintaining structural integrity. See the Snow Guards Compatibility Chart for ACI Building Systems UltraLok Standing Seam Metal Roofing Panels.

This roofing system features a design that offers multiple snow retention solutions. It is well-suited for adhesive-mounted polycarbonate snow guards. Still, it is crucial to apply the adhesive correctly to prevent issues like refreezing and detachment due to moisture. Customers can select from a wide range of snow guard options, including larger models such as IceJax II, Snojax II, and SnoBlox Ace, as well as smaller models like the Deuce and IceJax I. For increased safety during snow and ice shedding, we suggest using the SnowBreaker and SnowBreaker 3M. The rib configuration of the panel appears to be compatible with various clamp-on snow guards, including SnoCleat RC, SnoCleat RCT, SnoBar, and ColorBar rail systems, which can be mounted using either standard stainless steel SnoBar clamps or aluminum RoofClamp alternatives. Testing-fit a clamp sample before finalizing an order for one of these systems is advisable.

Considerations for Adding Snow Guards to Standing Seam Roofs by ACI Building Systems

Evaluate Snow Load Capacity

Investigate your area's "ground snow load" to guide your snow retention system selection. While most individual pad-style guards can manage up to 45 psf, regions with heavier snowfall demand more robust snow rail systems. For loads surpassing 45 psf on roofs unsuitable for snow rails, consult the panel manufacturer.

Design a Comprehensive Snow Retention Layout

Develop a thorough snow retention strategy for your entire roof. You may need multiple ascending rows extending the affected roof area(s) length to achieve a balanced load distribution. Position pad-style guards in a staggered pattern and align snow rails in straight rows. Avoid isolated installations above only specific areas to prevent overloading. Use our free resources, spacing guides, and quote forms to refine your design.

Enhance Ice Management

Consider upgrading your SnoBar or ColorBar systems on standing seam roofs with IceStopper attachments, particularly above high-traffic areas. You can incorporate these during initial installation or retrofit later. Ensure proper spacing to prevent ice slippage, especially with taller seams.

Strategize Installation Timing

Aim for late spring or early summer installation for adhesive-mounted polycarbonate snow guards. The popular Surebond SB-190 adhesive requires about 28 days at 50°F (10°C) to cure fully, though it becomes rain-resistant within 24 hours.

Adopt Non-Invasive Installation Techniques

Avoid directly attaching snow retention systems to standing seam metal roofs using penetrating hardware. This method can damage panels, compromise weather protection, and lead to costly repairs due to natural thermal expansion. Instead, opt for clamp-on or adhesive-mounted solutions to maintain compatibility and preserve your warranty.

Ensure System Compatibility

Before installation, test sample snow guards, clamps, brackets, or IceStoppers on your specific roof type. This crucial step prevents expensive mistakes and ensures seamless integration of all components.

Blend Aesthetics with Functionality

You can make your snow retention system complement your roof's appearance. Explore customizable metal inserts for ColorBar and SnoCleat products to match or contrast colors. These can be made from leftover roofing material or purchased with new systems. Alternatively, consider powder coating for full coverage and precise color matching. Local options may offer quicker turnaround times when speed is essential.

Conclusion

SnoBlox-Snojax offers extensive support for snow guard installations, providing a range of resources and tailored assistance to help clients achieve the best results. Our team is always available to answer questions or resolve any issues that may arise during the installation process, and we encourage customers to contact us via email or phone for help. We have created various informational tools to improve your understanding and enhance your installation success. Our Snow Guard Buyer's Guide delivers essential insights for making informed choices, while our "What Works and What Doesn't" page offers practical tips and identifies potential challenges, aiding customers in navigating the installation process more efficiently. We strongly advise clients to utilize these resources to understand our snow guard solutions thoroughly. By offering high-quality products and equipping our customers with knowledge and expertise, we aim to maximize the effectiveness of our solutions in real-world applications. Our commitment goes beyond product quality, encompassing comprehensive customer support to ensure clients have all the necessary tools and information for successful snow guard installations.
