Snow Guards For Standing Seam Metal Roof Panels by All Weather Insulated Panels (AWIP)

See the Snow Guards Compatibility Chart for All Weather Insulated Panels (AWIP) Standing Seam Metal Panels.

"What Are the Best Snow Guards for Metal Roofs?"

Ensuring the safety of property, people, and pets that can be negatively impacted (see what I did there) by snow avalanches from standing seam metal roofs during the winter months requires specialized knowledge and tailored solutions. This comprehensive guide explores various snow guards and snow retention systems, focusing on those compatible with AWIP's concealed fastener roof panel. We aim to provide essential information for selecting the most appropriate snow guard solution for your needs and contribute to an innovative, growing snow guard compatibility database. As part of this ongoing educational blog series, we highlight prominent metal panel manufacturers and our corresponding snow retention systems. By offering crucial insights, we strive to empower readers to make well-informed decisions that protect their investments and ensure the safety of building occupants, passersby, property, and pets during severe winter conditions. Effective snow retention strategies minimize the risks of sliding snow and ice.

Standing Seam Metal Roof Panels by All Weather Insulated Panels (AWIP)

All Weather Insulated Panels (AWIP) stands at the forefront of innovation in insulated metal panels and roof deck solutions. With a focus on creating cutting-edge building envelope systems, AWIP combines energy efficiency, design flexibility, and cost-effective construction methods. The company operates three advanced manufacturing facilities strategically located across the United States, enabling them to address the evolving energy, environmental, and economic challenges faced by the North American construction sector. AWIP's product lineup includes insulated wall and roof panels, roof deck systems, diverse finishes, and complementary accessories. These products meet the exacting standards of architects, engineers, and contractors working on commercial, industrial, and controlled environment projects. By emphasizing technological advancements and modern manufacturing processes, AWIP has positioned itself as a crucial player in the industry, particularly in addressing the growing demand for energy-efficient and sustainable building solutions. Their commitment to innovation and quality has made them a go-to resource for professionals seeking high-performance building materials that meet aesthetic and functional requirements.

Standing Seam (SR2) Roof Panel

The Standing Seam (SR2) Roof Panel offers a cutting-edge roofing solution that marries the timeless appeal of conventional metal standing seam roofs with the advanced functionality of insulated metal panels. This innovative design features a generous 40-inch (1016mm) width. It is distinguished by its 2-inch high ribs, resulting in a contemporary and streamlined appearance. The SR2 panel is available in 26 gauge G90 galvanized or AZ50 galvalume steel, with 24 and 22-gauge options for enhanced durability. This versatility in material selection allows for customization to meet specific project requirements. Designed for efficient installation, the SR2 panel comes in lengths ranging from 8 feet (2.44m) to an impressive 50 feet (15.24m). The minimum slope requirement of 1/2:12 ensures proper water runoff. At the same time, the exterior standing seam and interior tongue and groove side lap design contribute to the panel's excellent weather resistance and structural integrity. One of the SR2 panel's most notable features is its all-in-one design, which integrates an exterior weather barrier, insulation layer, vapor barrier, and interior finish into a single component. This comprehensive approach simplifies the roofing process, reducing installation time and costs compared to traditional field-assembled systems. The hidden fastener joinery system enhances weather protection and maintains a clean, uninterrupted exterior appearance. The SR2 panel's construction, which combines high-grade steel with polyisocyanurate foam, results in a roofing solution that is both lightweight and robust. This composition also contributes to the panel's superior energy efficiency, making it an excellent choice for projects prioritizing sustainability and long-term cost savings. Suitable for new construction and retrofit applications, the Standing Seam (SR2) Roof Panel from AWIP offers architects and building owners a roofing solution that doesn't compromise aesthetics, performance, or efficiency. Its blend of traditional standing seam aesthetics with modern insulated panel technology makes it a versatile and attractive option for a wide range of commercial and industrial buildings. See the Snow Guards Compatibility Chart for All Weather Insulated Panels (AWIP) SR2 Standing Seam Metal Panels.

Due to this panel's unusual design, the options for snow retention are minimal. Regarding adhesive-mounted snow guards, the striations of this panel only accommodate our SnoBlox Deuce for snow retention and the SnowBreaker and SnowBreaker 3M for those who wish to control the shedding of snow and ice. They accomplish this task by breaking the snow and ice into smaller, safer chunks. Covering the guards' entire base in glue is imperative to seal the area between the guards and the panels fully. Inadequate sealing could lead to snowmelt accumulation, refreezing, and eventual system failure due to guard detachment. Thanks to its rib configuration, this panel is compatible with various clamp-on snow guards such as SnoCleat RC, SnoCleat RCT, and ColorBar systems, which can be attached using standard stainless steel SnoBar clamps or aluminum RoofClamp clamping options. Only the aluminum ColorBar system is compatible with this panel, as the galvanized SnoBar is only compatible with panels up to 24" wide.

All Weather Insulated Panels (AWIP) Compatibility Chart for Snow Guards

Considerations for Adding Snow Guards to Standing Seam Roofs by All Weather Insulated Panels (AWIP)

Ensuring Color Harmony

Match snow retention system colors to elevate your roof's visual appeal. Our ColorBar and SnoCleat products accept optional, adaptable metal inserts that blend with your roof color or create striking contrasts. These can be acquired from us or crafted on-site using surplus roofing material. For precise color matching, consider our optional full-coverage powder coating services at an additional fee. Alternatively, those seeking greater color control or quicker turnaround may opt for DIY painting or local powder coating services.

Optimal Installation Timing

Plan to mount adhesive-based polycarbonate snow guards in late spring or early summer. The industry-preferred Surebond SB-190 adhesive requires approximately 28 days at 50°F (10°C) for complete curing, with rain resistance developing after about 24 hours.

Snow Load Assessment

Determine your area's "ground snow load" to select an appropriate snow retention system. Most individual pad-style guards can effectively handle snow loads up to 45 psf. Regions with heavier snowfall necessitate more robust rail systems. For roofs unsuitable for snow rails and ground snow loads exceeding 45 psf, consult the panel manufacturer for guidance.

Installation Best Practices

Refrain from directly fastening snow guards or rails to standing seam metal roofs with penetrating screws. This improper technique often results in panel damage, leaks, and costly repairs due to the natural expansion and contraction of the panels. Instead, opt for clamp-on or adhesive-mounted systems to ensure compatibility and maintain warranty coverage.

Comprehensive Layout Design

Develop a thorough snow retention strategy covering the entire roof length, typically employing multiple ascending rows for balanced weight distribution. Arrange individual pad-style snow guards in a staggered pattern and snow rails in straight lines. To prevent system overload, avoid isolated installations above doorways, walkways, or chimneys. Utilize our complimentary resources, spacing guides, and custom quote forms to optimize your design.

Compatibility Verification

Confirming the compatibility of your chosen snow retention components before full-scale implementation is crucial. Obtain individual samples or small kits to test-fit snow guards, clamps, brackets, or IceStoppers on your roof type. This proactive approach will prevent costly mistakes and ensure an ideal fit for your project.

Ice Formation Management

Enhance SnoBar or ColorBar rail systems on standing seam roofs with IceStopper attachments, particularly above high-traffic pedestrian areas. Installers can add these accessories during the initial installation or retrofit later. Proper spacing is essential, especially for seams taller than 1 inch, to prevent ice from slipping beneath the bar.

Conclusion

SnoBlox-Snojax is committed to providing exceptional support for snow guard installations, offering a wealth of resources and personalized assistance to ensure project success. Our expert team stands ready to address any inquiries you might have throughout this process. For tailored guidance, we encourage you to reach out via email at support@snojax.com or call us at 1-800-766-5291. To complement our direct support, we've developed various informational tools to enhance your understanding and execution of snow guard installations. Our comprehensive Snow Guard Buyer's Guide offers crucial insights to aid decision-making. Our "What Works and Doesn't" page also provides practical tips. It highlights potential pitfalls to avoid, ensuring a smoother installation experience. We strongly recommend taking full advantage of these resources to understand our snow guard solutions thoroughly. At SnoBlox-Snojax, we pride ourselves on delivering top-tier products and equipping our customers with the essential knowledge needed to maximize the effectiveness of our solutions in real-world scenarios. Our commitment extends beyond mere product provision; we strive to empower our clients with the expertise required to achieve optimal results in their snow guard installations.

Disclaimer

The views, recommendations, and information presented in this blog are solely those of the author and do not necessarily reflect the opinions or positions of the featured panel manufacturer, its brands, subsidiaries, or parent companies. Customers are strongly encouraged to reach out directly to the roof panel manufacturer for inquiries regarding snow guard compatibility with their products, as well as to address any potential warranty issues that may arise following the installation of our products.
